Description
8 MIL Premium Clear Durable Overlaminate
An affordable alternative to Ultracurve® 1000, this film strikes the ideal balance between conformability and durability, Ultracurve® 800 is the perfect choice for applications that don’t require the ultimate level of protection.
Ultracurve® 800 was co-developed with the World’s leading racers, designed specifically for the rigors of powersports.
Nothing competes with the gloss, clarity, and appearance of Ultracurve® 800.
The 203 micron thickness of Ultracurve® 800 offers good abrasion and wear resistance in harsh environments.
Highlights
- Developed as a Thinner Alternative to Ultracurve® 1000
- 203 micron thickness offers good abrasion and wear resistance in harsh environments
- Solvent-Based Acrylic Adhesive
- High Durability and Conformability for Easy Application
- UV Extenders Protect Against Premature Fading
- Ultra-Smooth 93LB Release Liner Reduces Silvering
- Nothing competes with the gloss, clarity, and appearance of Ultracurve® 800
Applications
- Snowmobile Graphics
- UTV Graphics
- Durable Labels
- Protective Applications
Ink Compatibility
- Solvent
- Eco-Solvent
- Latex
- UV-Curable
- Thermal Transfer
Product Specifications
| Material | 203 micron Engineered Calendered Vinyl |
|---|---|
| Colour | Clear |
| Tensile Strength | 336N/25mm |
| Adhesive | Clear Solvent-Based Pressure Sensitive Acrylic |
| Adhesive Thickness | 0.056mm +/- 10% |
| Peel Adhesion | 24N/25mm from Stainless Steel |
| Liner | 90LB Natural Brown PE Coated Layflat Paper |
| Liner Release | 32 grams/25mm |
| Dimensional Stability | 0.8 mm |
| Application Temperature | 5°C to 27°C recommended, test prior to specific application |
| Temperature Range | -53°C to 104°C |
| Shelf Life | 6 months when stored at 21°C and 50% relative humidity |
| Print Compatibility | N/A |
| Graphic Life | Outdoor durability up to 3 years, permanent |
| Chemical Resistance | Resists mild acids, mild akalis, solvents, and salts. Excellent resistance to water, including immersion. |
