Substance Incorporated recommends the following end uses for ICON® 440LSE: Excellent adhesion to a wide variety of smooth and textured HSE/LSE plastics. Graphics and wall murals applied to brick, unsealed concrete, and stucco. Sidewalk and Pavement graphics when combined with ICON® 6100 overlaminate. Permanent adhesion to almost any low surface energy or difficult substrate.
|Material||82 micron Polymeric Calendered Vinyl|
|Adhesive||Clear Solvent-Based Pressure Sensitive Acrylic|
|Adhesive Thickness||0.038mm +/-10%|
|Peel Adhesion||28N/25mm from Stainless Steel|
|Liner||93LB PE Coated Layflat Paper|
|Liner Release||30 grams/25mm|
|Dimensional Stability||0.9 mm|
|Application Temp.||0°C to 27°C recommended, test prior to specific application|
|Temperature Range||-53°C to 104°C|
|Shelf Life||2 years when stored at 21°C and 50% relative humidity|
|Print Compatability||Solvent, Eco-Solvent, Latex, UV, and Thermal Transfer Inks|
|Graphic Life||Outdoor durability up to 7 years (unprinted), permanent|
|Chemical Resistence||Resists mild acids, mild akalis, solvents, and salts. Excellent resistance to water, including immersion.|
Before applying an overlaminate, allow 24-48 hours for print to dry. Application surface must be free of dust, dirt, debris, grease, and other contaminants. We highly recommend cleaning the installation surface with isopropyl alcohol prior to application. Dry installation is recommended. Due to a highly-aggressive adhesive system, 440LSE will exhibit a slightly higher amount of shrinkage than standard calendered vinyl films.
