Description
70 micron Premium Polymeric Overlaminate
A premium polymeric overlaminate with UV protection. ICON® PL-3150 is the premier choice for short to medium-term graphic protection. High-clarity solvent-based adhesive and UV absorbers extend the life of your printed graphics, preventing premature fading and discoloration.
The vast majority of calendered films use inferior monomeric and blended plasticizers in their construction. ICON® PL-3150 utilizes 100% polymeric plasticizer for superior longevity, durability, flexibility, and shrinkage-resistance.
Excellent clarity and fast wet-out for true color reproduction without tonal shift.
ICON® PL-3150 utilizes UV absorbers to extend the life of printed graphics, preventing premature fading and discoloration.
Highlights
- 100% Polymeric Construction
- 70 micron Film Thickness with Exceptional Clarity
- UV Extenders Protect Against Premature Fading
- Optimized for Flat to Moderately Curved Surfaces
- Ultra-Smooth 93LB Release Liner Reduces Silvering
- Low Shrinkage for Improved Longevity
- ASTM E-84-17 Class A Fire Rating
- Outdoor Durability up to 6 Years
Applications
- Race Car & Boat Graphics
- Trade Show & POP Graphics
- Floor Graphics
- Stickers
- High-End Signage & Decals
- Wall Graphics, Murals, & Wraps
- Window & Storefront Graphics
Ink Compatibility
- Solvent
- Eco-Solvent
- Latex
- UV-Curable
- Thermal Transfer
Product Specifications
| Material | 70 micron Polymeric Calendered Vinyl |
|---|---|
| Colour | Clear |
| Tensile Strength | 55.6N/25mm |
| Adhesive | Solvent-Based Pressure Sensitive Acrylic |
| Adhesive Thickness | 0.028mm +/-10% |
| Peel Adhesion | 20N/25mm from Stainless Steel |
| Liner | 90LB PE Coated Extra Smooth Layflat Paper |
| Liner Release | 30 grams/25mm |
| Dimensional Stability | 0.5 mm |
| Application Temperature | 10°C to 32°C recommended, test prior to specific application |
| Temperature Range | -40°C to 88°C |
| Shelf Life | 2 years when stored at 21°C and 50% relative humidity |
| Print Compatibility | Solvent, Eco-Solvent, Latex, UV, and Thermal Transfer Inks |
| Graphic Life | Outdoor durability up to 5 years, permanent |
| Chemical Resistance | Resists mild acids, mild akalis, solvents, and salts. Excellent resistance to water, including immersion. |
