Description
152 micron Textured Anti-Slip Floor Graphic Overlaminate
This textured overlaminate is engineered for traction and durability in floor graphic and protective applications. Meeting UL-410 requirements, this overlaminate offers optimal clarity, zero silvering, and an extended lifespan for applications requiring traction, scratch resistance, and protection.
The vast majority of calendered films use inferior monomeric and blended plasticizers in their construction. ICON® TL-6100 utilizes 100% polymeric plasticizer for superior longevity, durability, flexibility, and shrinkage-resistance.
Highlights
- 100% Polymeric Construction
- 152 micron Total Product Thickness
- Textured Surface Meets UL-410 Anti-Slip Requirements
- Durable Finish Resists Scratching and Abrasion
- UV Extenders Protect Against Premature Fading
- Polyester Release Liner Eliminates Silvering
- Low Shrinkage for Improved Longevity
- ASTM E-84-17 Class A Fire Rating
- Outdoor Durability up to 6 Years
Applications
- Industrial Decals & Heavy Equipment
- POP & Trade Show Graphics
- Nameplates & Overlays
- Pipeline Markings
- Display Graphics
- Floor & Sidewalk Graphics
Ink Compatibility
- Solvent
- Eco-Solvent
- Latex
- UV-Curable
- Thermal Transfer
Product Specifications
| Material | 153 micron Polymeric Calendered Vinyl |
|---|---|
| Colour | Clear |
| Tensile Strength | 170N/25mm |
| Adhesive | Solvent-Based Pressure Sensitive Acrylic |
| Adhesive Thickness | 0.038mm +/-10% |
| Peel Adhesion | 23N/25mm from Stainless Steel |
| Liner | Clear 2.0mil Polyester Release Liner |
| Liner Release | 30 grams/25mm |
| Dimensional Stability | 0.5 mm |
| Application Temperature | 10°C to 32°C recommended, test prior to specific application |
| Temperature Range | -40°C to 88°C |
| Shelf Life | 2 years when stored at 21°C and 50% relative humidity |
| Print Compatibility | N/A |
| Graphic Life | Outdoor durability up to 5 years, permanent |
| Chemical Resistance | Resists mild acids, mild akalis, solvents, and salts. Excellent resistance to water, including immersion. |
