Description
Recommended Uses
Substance Incorporated ICON® EM3 exhibits the following product features and advantages: • Economy polymeric hybrid print media with solvent-based adhesive that significantly outperforms other products in its class. • Broad adhesion to a wide variety of surfaces with excellent handling characteristics and easy application. • Polymeric hybrid film offers good dimensional stability, and clean long-term removability from virtually all surfaces. • An excellent choice for short to medium-term indoor and outdoor signage applications lasting up to four years. • Phthalate-Free Film Structure and ASTM E84-17 Class A rating conform to the highest heath and safety standards.
Performance
| ICON® EM3 | |
| Material | 77 micron Polymeric Hybrid Calendered Vinyl |
| Colour | Opaque White |
| Tensile Strength | 52.5N/25mm |
| Adhesive | Clear Solvent-Based Pressure Sensitive Acrylic |
| Adhesive Thickness | 0.02mm +/-10% |
| Peel Adhesion | 19N/25mm from Stainless Steel |
| Liner | 92LB PE Coated Layflat Paper |
| Liner Release | 30 grams/25mm |
| Dimensional Stability | 0.75 mm |
| Application Temp. | 10°C to 32°C recommended, test prior to specific application |
| Temperature Range | -40°C to 100°C |
| Shelf Life | 2 years when stored at 21°C and 50% relative humidity |
| Print Compatability | Solvent, Eco-Solvent, Latex, UV, and Thermal Transfer Inks |
| Graphic Life | Outdoor durability up to 4 years (unprinted), permanent |
| Chemical Resistence | Resists mild acids, mild akalis, solvents, and salts. Excellent resistance to water, including immersion |
Installation
Before applying an overlaminate, please allow 24-48 hours for solvent ink systems to dry. Application surface should be free of dust, dirt, debris, grease, and other contaminants. It is highly recommended to clean the installation surface with isopropyl alcohol prior to application. Dry installation is recommended. If a wet installation is desired, please test application fluid prior to use in a production environment.
